Monarch v3: NES-Inspired KV Paging for 78% Faster LLM Inference

What Monarch v3 Does

Monarch v3 is an open-source implementation of NES-inspired memory paging for transformer inference that addresses the linear growth of KV cache with sequence length. By 4K tokens, most KV cache sits unused while consuming VRAM at full precision.

How It Works

The system splits KV cache into two regions:

• Hot region: Recent tokens kept at full precision
• Cold region: Older tokens compressed to ~20 bytes each (vs 64-128 bytes hot)

Four components work together:

• TurboQuant Compression: Quantizes KV to 4-bit integers with polar encoding and residual correction, achieving ~97% size reduction with ~0.3% perplexity loss
• Sliding Window Eviction: Recent N tokens stay hot by default, old tokens compress to cold storage
• Attention-Weighted Promotion: High-attention tokens move back to hot with sticky mechanism to prevent thrashing
• Page Swaps: Small batches of cold tokens materialize on access with local decode loop replacing batch matmul

Benchmark Results

Setup: TinyLlama-1.1B fp16, 50 generated tokens

• Standard: 17.01 tok/s, 2112 MB VRAM
• Monarch-v3: 30.42 tok/s, 2131 MB VRAM, 512 hot tokens, 1024 cold tokens
• Gain: +78.7% throughput, +0.9% VRAM

Simplified Decode Loop

for step in 1..100:
    q = project_query(next_token)
    # Compute attention: hot only (fast)
    scores_hot = q @ kv_hot.T
    # Access cold if high attention (rare)
    if max(scores_hot) < threshold:
        kv_cold_promoted = decompress(cold_pages)
        scores_cold = q @ kv_cold_promoted.T
        # Move to hot for next step
    # Aggregate, softmax, apply attn ...
    # Evict old tokens from hot → cold
    if len(kv_hot) > window_size:
        evict_oldest_to_cold()

Current Status

• Implementation: Working on Hugging Face Transformers with custom cache backend
• License: Apache 2.0
• Paper: Full technical spec available
• Next: CUDA kernel fusion for cold decompression planned

How to Try It

git clone https://github.com/JohannaWeb/Monarch.git
cd Monarch
pip install -r requirements.txt
python train_tinyllama_fp16.py
python src/benchmark_monarch.py \
    --model models/tinyllama_fp16 \
    --mode both \
    --max-new-tokens 100 \
    --promotion-threshold 0.15 \
    --sticky-threshold 3 \
    --json

Limitations

The approach relies on recency (recent tokens = high attention), which works for most tasks but may not for retrieval-heavy workloads. Attention extraction is available in base models but not chat variants; fallback uses window-only paging.
